Transistor Type
2 NPN (dual)
Current - Collector (Ic) (max)
200mA
Voltage - Collector Emitter Breakdown (Max)
40V
Vce saturation voltage drop at different Ib, Ic (maximum)
300mV @ 5mA, 50mA
Current - Collector Cutoff (Maximum)
-
DC current gain (hFE) at different Ic, Vce (min)
100@10mA, 1V
Power - max
150mW
frequency - transition
300MHz
Operating temperature
-55°C ~ 150°C (TJ)
installation type
Surface Mount Type
Package/Enclosure
6-TSSOP, SC-88, SOT-363
Supplier Device Packaging
SC-88/SC70-6/SOT-363
Basic product number
MBT3904
