output type
transistor driver
Function
boost, boost/buck
output configuration
Positive, can provide isolation
topology
flyback, boost
Number of outputs
1
output stage
1
Voltage - Supply (Vcc/Vdd)
7.6V ~ 30V
Frequency - Switch
up to 500kHz
Duty cycle (max)
48%
Synchronous Rectifier
none
Clock synchronization
none
serial interface
-
Control characteristics
frequency control
Operating temperature
0°C ~ 70°C (TA)
installation type
Surface Mount Type
Package/Enclosure
8-SOIC (0.154", 3.90mm wide)
Supplier Device Packaging
8-SOIC
Basic product number
UC3845
