type
Clock/Calendar
characteristic
Siren, Leap Year, Square Wave Output, SRAM, TCXO/Crystal
storage
236B
Time format
HH:MM:SS (12/24 hours)
date format
YY-MM-DD-dd
interface
I2C, 2-wire serial
Voltage - Powered
2.3V ~ 5.5V
Voltage - power supply, battery
2.3V ~ 5.5V
Current - Timing (Max)
120μA ~ 160μA @ 3.3V ~ 5.5V
Operating temperature
-40°C ~ 85°C
installation type
Surface Mount Type
Package/Enclosure
20-SOIC (0.295", 7.50mm wide)
Supplier Device Packaging
20-SOIC
Basic product number
DS3232
