category
Integrated Circuit (IC)
Data Acquisition-Digital-to-Analog Converter (DAC)
manufacturer
Analog Devices Inc.
Package
Tape and Reel (TR)
Shear Band (CT)
Number of digits
8
Number of digital-to-analog converters
2
Build time
2μs
Output type
Voltage-Buffered
Differential output
none
Data interface
in parallel
Reference type
external
Voltage-power supply, analog
2.7V ~ 5.5V
Voltage-power supply, digital
2.7V ~ 5.5V
INL/DNL (LSB)
±1 (maximum), ±1 (maximum)
Architecture
current source
Operating temperature
-40°C ~ 105°C
Encapsulation/Shell
20-TSSOP (0.173", 4.40mm width)
Supplier device packaging
20-TSSOP
Type of installation
Surface mount type
Basic product number
AD7302
