Detection distance: 4mm ± 10%
Set distance: 0~3.6mm
Current: 5V 360mA, 12V 200mA, 24V 96mA, maximum instantaneous current 2A
Delay distance: 10% below of the detection distance
Detection object: Magnetic metal(the detection distance decreases when it is non-magnetic metal)
Stand detection object: Iron 15*15*1mm
Response frequency: DC:0.5kHz
Supply voltage: DC type:DC12V DC24V DC36V(5~36V)impulse(p-p)10% below
Withstand voltage: AC1000V 50/60Hz 1min between charging part and housing
Meterial: (Housing:Nickel plated brass) (Detection surface:ABS)
Protection influence: IP67(IEC specification)
This product can be applied to control relays, counters,PLC, etc
