Automotive Yes Body Orientation Straight Maximum Current Rating - (A) 0.05@32VDC Maximum Power Rating - (VA) 1@32VDC Mechanical Life - (Cycles) 300000 Military No Operating Force - (N) 3 Operating Temperature - (??C) -40~85 Packaging Tape and Reel Rad Hard No Switch Configuration N.O. Switching Function Momentary Termination Style Gull Wing EU RoHS Compliant ECCN (US) EAR99 Part Status Active HTS 8536.50.90.65 Pole Throw Configuration SPST Actuator Style Round Button Maximum Current Rating (A) 0.05@32VDC Maximum Power Rating (VA) 1@32VDC Dielectric Strength 250VAC Minimum Insulation Resistance (MOhm) >10 Maximum Contact Resistance (mOhm) <100 Mechanical Life (Cycles) 300000 Operating Force (N) 3 Actuator Length (mm) 0.87 Number of Rows 2 Row Spacing (mm) 8.9 Mounting Surface Mount Number of Terminals 4 Terminal Length (mm) 1.9 Terminal Pitch (mm) 4 IP Rating IP40|IP67 Minimum Operating Temperature (°C) -40 Maximum Operating Temperature (°C) 85 Body Length (mm) 6.2 Body Depth (mm) 6.2 Body Height (mm) 2.7 Product Length (mm) 6.2 Product Depth (mm) 10 Product Height (mm) 3.5 Contact Material Silver Actuator Type Tactile Contact Configuration SPST Contact Current Rating 50 mA Maximum Operating Temperature +85°C Mechanical Life 300000Operace Minimum Operating Temperature -40°C Mounting Type Surface Mount Operating Force 3±0.75 N Operating Temperature Range -40 →+85°C Switch Operation Momentary Terminal Type Gull Wing Voltage Rating 32V dc Width 6.2mm
